GableBreeze™ Solar Gable Fans

A smarter way to move air. Without changing your roof.

Designed to work with your home's existing gable vents, GableBreeze uses solar power to help move trapped heat and moisture out of your attic. Powerful ventilation that works with the home you already have.

Charcoal craftsman home with board-and-batten gables and gable vents, surrounded by sunlit trees
Round louvered gable vent on dark lap siding beneath a white soffit and roofline

The benefits of GableBreeze

Good for Your Attic. Easy on Your Roof.

Your home already has a design worth keeping. GableBreeze works with an existing gable vent to help move trapped heat and moisture out of your attic without requiring a new roof opening for the fan.

Keep Your Roof Intact

GableBreeze installs behind an existing gable vent, providing powered ventilation without requiring a new opening in your roof for the fan.

Help Your Home Handle the Heat

Hot air can build up in your attic throughout the day. GableBreeze helps push that trapped heat outside, supporting a more comfortable home.

Help Manage Moisture Buildup

Moisture can collect in an attic when air isn't moving properly. GableBreeze helps exhaust humid air as part of a properly designed ventilation system.

Engineered for the job

Serious airflow. Thoughtful engineering.

A simple install, backed by durable materials, efficient components, and solar-powered performance.

14-inch aluminum blade

Precision-Balanced Fan Blade

14-inch aluminum blade with five precision-balanced blades.

PowerMaxx™ motor

Performance at the Core

Variable-speed DC motor that works with the sunlight available. Rated under 30 dB.

Zincalume alloy steel

Corrosion-Resistant Construction

Zincalume alloy steel with stainless steel brackets and hardware.

Monocrystalline solar panel

Remote Solar Panel

Monocrystalline PERC panel with impact-resistant tempered glass.

Thermal switch + fire safety

Temperature and Safety Controls

Thermal switch turns the fan on near 75°F and off near 55°F. Fire safety cutoff included.

Cream board-and-batten gable with a louvered vent, and a solar panel mounted on the sunny roof beside it

Flexible solar power

The fan goes where it's needed. The panel goes where the sun is.

GableBreeze installs behind an existing gable vent or louver, while its remote solar panel can be positioned separately to capture available sunlight.

A 25-foot weather-resistant power cable is included, with an additional 25 feet available when needed.

The panel can be positioned on a suitable roof or wall surface using the appropriate mounting hardware.

The GableBreeze lineup

The right airflow for the space above.

From smaller attic spaces to larger ventilation needs, GableBreeze offers four solar-powered performance options.

GableBreeze

PRO

25W panel

GableBreeze

HP

35W panel

GableBreeze

MAX

45W panel

GableBreeze

ELITE

65W panel

PRO specifications

Performance
  • Max airflow1,550 CFM
  • Attic coverageUp to 2,000 sq. ft.
  • Minimum intake (NFVA)6.0 sq. ft.(864 sq. in.)
  • Noise levelUnder 30 dB
Power Source
  • Solar panel25W, remote mounted
  • Power cable25 ft includedAdditional 25 ft available
Construction & weight
  • Fan blade14-inch aluminum
  • Fan unit9.0 lb
  • Panel / combined5.5 / 14.5 lb
Part number & warranty
  • Gable mountAB-2553G
  • Residential WarrantyLifetime Limited Parts Warranty
  • DocumentationTechnical Data Sheet
Performance
  • Max airflow1,775 CFM
  • Attic coverageUp to 2,500 sq. ft.
  • Minimum intake (NFVA)7.0 sq. ft.(1,008 sq. in.)
  • Noise levelUnder 30 dB
Power Source
  • Solar panel35W, remote mounted
  • Power cable25 ft includedAdditional 25 ft available
Construction & weight
  • Fan blade14-inch aluminum
  • Fan unit9.0 lb
  • Panel / combined5.5 / 14.5 lb
Part number & warranty
  • Gable mountAB-3553G
  • Residential WarrantyLifetime Limited Parts Warranty
  • DocumentationTechnical Data Sheet
Performance
  • Max airflow1,925 CFM
  • Attic coverageUp to 3,000 sq. ft.
  • Minimum intake (NFVA)7.5 sq. ft.(1,080 sq. in.)
  • Noise levelUnder 30 dB
Power Source
  • Solar panel45W, remote mounted
  • Power cable25 ft includedAdditional 25 ft available
Construction & weight
  • Fan blade14-inch aluminum
  • Fan unit9.0 lb
  • Panel / combined6.9 / 15.9 lb
Part number & warranty
  • Gable mountAB-4553G
  • Residential WarrantyLifetime Limited Parts Warranty
  • DocumentationTechnical Data Sheet
Performance
  • Max airflow2,150 CFM
  • Attic coverageUp to 4,000 sq. ft.
  • Minimum intake (NFVA)8.5 sq. ft.(1,224 sq. in.)
  • Noise levelUnder 30 dB
Power Source
  • Solar panel65W, remote mounted
  • Power cable25 ft includedAdditional 25 ft available
Construction & weight
  • Fan blade14-inch aluminum
  • Fan unit9.0 lb
  • Panel / combined9.4 / 18.4 lb
Part number & warranty
  • Gable mountAB-6553G
  • Residential WarrantyLifetime Limited Parts Warranty
  • DocumentationTechnical Data Sheet

Installation essentials

The Right Setup Makes All the Difference.

The Right Gable Opening

GableBreeze installs behind an existing gable vent or louver. The opening must be properly sized for the fan and the space being ventilated.

Adequate Intake Ventilation

Air needs a way in before it can be pushed out. Adequate intake ventilation and a clear airflow path are essential for GableBreeze to effectively exhaust trapped heat and moisture.

Solar Panel Placement

The remote solar panel can be installed separately from the fan, allowing it to receive sunlight where it's most available. A secure mounting location and appropriate cable reach are important.

Cream and black horse barn with a gable vent above open sliding doors, set among trees and pasture fencing

Beyond the home

Big spaces need a little breathing room, too.

Not every building has an outlet nearby. And not every space that needs ventilation is part of your home.

From pole barns and workshops to storage buildings and equestrian properties, heat and moisture can build up beneath the roof.

GableBreeze uses solar power to help push that trapped air outside, without needing to run electrical power to the fan.

With adequate intake ventilation and a clear path for airflow, it's a practical option for keeping air moving through suitable spaces.

Frequently asked questions

Good Questions. Clear Answers.

Everything you need to know about GableBreeze solar gable fans, from installation and airflow to choosing the right model for your space.

GableBreeze adds active, solar-powered ventilation through an existing gable vent. It helps push built-up heat and humid air out of the attic while intake vents let replacement air in, without requiring a new roof opening for the fan.

Often, yes, as long as the vent is the right size and there's room behind it for the fan and its mounting. An installer will check the vent and the space inside the attic. Find an installer near you.

No new roof opening is needed for the fan when installing behind a suitable existing gable vent or louver. The remote solar panel mounts separately, and its cable must be routed appropriately for the installation.

The remote solar panel installs separately from the fan in a secure location with good sunlight. GableBreeze includes a 25-foot weather-resistant cable, with an additional 25 feet available if needed. The panel can be mounted on a suitable roof or wall surface using the appropriate hardware.

It depends on the size of the space, its intake ventilation, and installation conditions. The lineup above shows each model's coverage as a starting point. For a recommendation, try our Ventilation Calculator or ask an installer.

GableBreeze runs on power from its solar panel, so its speed follows the sunlight. It slows on cloudy days and rests at night. A built-in thermal switch also turns the fan on as the attic warms past about 75°F and off as it cools to about 55°F.

Yes. GableBreeze can be a good option for pole barns, workshops, storage buildings, and other suitable structures. It uses solar power, so there's no need to run electrical power to the fan. The building must have an appropriately sized gable opening, adequate intake ventilation, and a clear path for airflow. Ventilating the roof space does not automatically ventilate stalls or other areas below.

Homeowners can use Find an Installer to connect with a contractor near you. Contractors can find stocking distributors on Where to Buy.

Looking for specifications or installation documents? Explore GableBreeze Technical Resources

Find your fit

Good ventilation starts with the right fit.

Every home is different. Whether you're exploring GableBreeze for an existing gable vent or comparing attic ventilation options, we're here to help you find the right solution.
